Name: Cisco Catalyst 3650 48 Port Full PoE 4x1G Uplink IP Services
Brand: Cisco
SKU: WS-C3650-48FS-E
Price: 1200.00 USD
Availability: InStock
Rating: 4.8 (5 reviews)

Question 1

What is the Cisco Catalyst 3650 48FS-E (WS-C3650-48FS-E)?

Accepted Answer

The Cisco Catalyst 3650 48FS-E (WS-C3650-48FS-E) is a fixed-configuration Layer 3 switch featuring 48 Gigabit Ethernet PoE+ ports, four 1G uplinks, and an IP Services license for advanced routing and security in campus access networks.

Question 2

How many PoE+ ports does the WS-C3650-48FS-E provide and what is its power budget?

Accepted Answer

The WS-C3650-48FS-E provides 48 full PoE+ (802.3at) ports with a total power budget of 740 W, enabling support for IP phones, wireless access points, and surveillance cameras on every edge port.

Question 3

Which uplink interfaces are available on the Catalyst 3650 48FS-E?

Accepted Answer

This switch includes four fixed 1G SFP uplink ports to interconnect with aggregation switches or routers for resilient, high-speed backbone connectivity.

Question 4

What is the switching capacity and forwarding rate of the WS-C3650-48FS-E?

Accepted Answer

The WS-C3650-48FS-E offers 176 Gbps of switching capacity and a forwarding rate of up to 130.95 Mpps, ensuring wire-speed performance for demanding campus deployments.

Question 5

What Layer 3 features are enabled by the IP Services license?

Accepted Answer

With the IP Services license, the Catalyst 3650 48FS-E supports full Layer 3 routing—including OSPF, EIGRP, BGP, PIM, and VRF Lite—to deliver advanced enterprise routing, multicast, and segmentation.

Question 6

Can the Cisco Catalyst 3650 48FS-E be stacked with other switches?

Accepted Answer

Yes, it supports Cisco StackWise-160 technology for stacking up to nine switches with 160 Gbps of bi-directional stack bandwidth for unified management and resiliency.

Question 7

What are the main security features of the WS-C3650-48FS-E?

Accepted Answer

Key security capabilities include IEEE 802.1X authentication, Cisco TrustSec, Dynamic ARP Inspection, DHCP Snooping, and Control Plane Policing to protect against unauthorized access and network attacks.

Question 8

Which PoE standards are supported by the Catalyst 3650 48FS-E?

Accepted Answer

The switch supports IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards, delivering up to 30 W per port for high-power devices such as PTZ cameras and wireless access points.

Question 9

What QoS and traffic management features are available?

Accepted Answer

It offers comprehensive QoS with eight hardware queues per port, traffic shaping, policing, Weighted Fair Queuing (WFQ), and Low-Latency Queuing (LLQ) for deterministic application performance.

Question 10

How do I manage and configure the WS-C3650-48FS-E?

Accepted Answer

You can manage the switch via Cisco IOS CLI, Cisco Network Assistant, or Cisco DNA Center (with an additional license) for centralized provisioning, monitoring, and automation.

Question 11

What environmental specifications apply to the Catalyst 3650 48FS-E?

Accepted Answer

Operating temperature ranges from 0°C to 40°C, with humidity between 10% and 90% non-condensing, and it requires a 100–240 VAC, 50–60 Hz power input.

Question 12

What physical dimensions and form factor does the WS-C3650-48FS-E have?

Accepted Answer

The switch measures 1.72”×17.5”×17.5” (H×W×D), weighs approximately 15.4 lb, and fits standard 19” rack mounts with included brackets.

Question 13

What warranty and support options are available for the WS-C3650-48FS-E?

Accepted Answer

Cisco provides a limited lifetime hardware warranty with next-business-day replacement. Optional SMARTnet contracts offer 24/7 technical support and software updates.

Question 14

Which network roles suit the Cisco Catalyst 3650 48FS-E?

Accepted Answer

It is ideal for enterprise access-layer deployments, converged edge switching, PoE-driven environments, and medium-sized branch offices requiring advanced routing and security.

Question 15

Is redundant power supported on the Catalyst 3650 48FS-E?

Accepted Answer

Yes, you can install an optional Cisco RPS (Redundant Power System) to provide power redundancy and high availability for critical edge devices.

Question 16

How many VLANs and MAC addresses can the WS-C3650-48FS-E handle?

Accepted Answer

The switch supports up to 4,094 VLANs, 32,000 MAC address entries, and 9,000 IPv4 routes to accommodate large, segmented campus networks.

Question 17

Where can I find replacement modules and accessories for WS-C3650-48FS-E?

Accepted Answer

Cisco and authorized partners stock compatible SFP transceivers, power supplies, and fans; consult Cisco’s Spare Parts Locator or your reseller for specific SKUs.

	WS-C3650-48FS-E	WS-C3650-12X48UR-E	WS-C3650-48FQ-L	WS-C3650-8X24UQ-L
Depth	12.8 inches	16.4 inches	11.8 inches	11.8 inches
Ethernet Technology	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Flash Memory	256 MB	256 MB	256 MB	256 MB
Form Factor	Rack-mount	Rack-mount	Rack-mount	Rack-mount
Height	1.73 inches	1.73 inches	1.73 inches	1.75 inches
IOS	IP Services	IP Services	LAN Lite	LAN Lite
Interface Ports	10/100/1000	10/100/1000	10/100/1000	10/100/1000
Layer Supported	Layer 2 / Layer 3	Layer 2 / Layer 3	Layer 2 / Layer 3	Layer 2 / Layer 3
Manageable	Managed	Managed	Managed	Managed
Manufacturer Part Number	WS-C3650-48FS-E	WS-C3650-12X48UR-E	WS-C3650-48FQ-L	WS-C3650-8X24UQ-L
Media Type Supported	Twisted Pair / Fiber / Combo	Twisted Pair / Fiber / Combo	Twisted Pair	Twisted Pair / Fiber
Memory	4 GB	4 GB	512 MB	4 GB
Number of Downlink Ports	N/A	48 Ports	48 Ports	24 Ports
Number of Ethernet Ports	24–48 Ports	24–48 Ports	24–48 Ports	12–24 Ports
POE Support	POE+	POE+	POE+	Non POE
Port/Expansion Slot Details	48 x 10/100/1000 Ethernet ports, 4 x 1G SFP uplink ports	48 fixed Ethernet ports and 12 fixed 10G SFP+ uplink ports	48 x 10/100/1000 Ethernet ports, 4 x 1G/10G SFP+ uplink ports	24 x 10/100/1000 Ethernet ports and 8 x 10G SFP+ uplink ports
Power Consumption	350 W	370W	370W	370 W
Power Source	Redundant Power Supply / AC Power Supply	Redundant Power Supply / AC Power Supply	AC Power Supply	AC Power Supply
Product Name	Cisco Catalyst 3650 Series WS-C3650-48FS-E	Cisco Catalyst 3650 Series WS-C3650-12X48UR-E	Cisco Catalyst 3650 Series WS-C3650-48FQ-L	Cisco Catalyst 3650 8X24UQ-L Stackable Switch
Product Type	Switch	Switch	Switch	Switch
Rack Units	1 RU	1 RU	1 RU	1 RU
Redundant Power Supply Supported	Yes	Yes	No	No
SFP Ports	4 SFP Ports	12 SFP Ports	4 SFP Ports	8 SFP Ports
Switching Capacity	128 Gbps	160 Gbps	160 Gbps	160 Gbps
Switching Capacity with Stacking	160 Gbps	320 Gbps	160 Gbps	160 Gbps
Uplink Configuration	1G	10G	1G / 10G	10G
Weight	22 lbs	31 lbs	31 lbs	14 lbs
Width	17.32 inches	17.3 inches	17.5 inches	17.5 inches
