Name: IE 2000U 16X10/100 2 FE SFP 2 T/SFP GE PORTS W/ 1588 C
Brand: Cisco
SKU: IE-2000U-16TC-G-X
Price: 2113.00 USD
Availability: InStock
Rating: 4.7 (6 reviews)

Question 1

What is the IE-2000U-16TC-G-X industrial Ethernet switch?

Accepted Answer

The IE-2000U-16TC-G-X is a rugged, unmanaged industrial Ethernet switch featuring 16 10/100 RJ-45 ports, two Fast Ethernet SFP slots and two combo Gigabit Ethernet/SFP ports with IEEE 1588 Class C time-synchronization.

Question 2

How many copper and fiber ports does the IE-2000U-16TC-G-X provide?

Accepted Answer

This switch offers 16 10/100 RJ-45 copper ports, two 100 Mbps SFP fiber slots, and two combo ports that auto-negotiate between Gigabit RJ-45 and SFP.

Question 3

What is IEEE 1588 Class C on the IE-2000U-16TC-G-X?

Accepted Answer

IEEE 1588 Class C provides sub-microsecond clock accuracy for precise time-synchronization in automation and telecom applications.

Question 4

Is the IE-2000U-16TC-G-X managed or unmanaged?

Accepted Answer

The IE-2000U-16TC-G-X is an unmanaged switch, delivering plug-and-play connectivity without complex configuration.

Question 5

What is the switching capacity of the IE-2000U-16TC-G-X?

Accepted Answer

It delivers a non-blocking switching capacity of 8.8 Gbps and a forwarding rate of up to 6.55 Mpps.

Question 6

What are the operating temperature specifications?

Accepted Answer

The IE-2000U-16TC-G-X operates reliably in temperatures from –40 °C to +75 °C for harsh industrial environments.

Question 7

What power input options does the IE-2000U-16TC-G-X support?

Accepted Answer

It supports a wide AC input range of 100–240 VAC or DC input of 12–48 VDC for flexible deployment.

Question 8

Does the IE-2000U-16TC-G-X support redundant power supplies?

Accepted Answer

Yes, it includes dual power-input terminals for redundant power configuration and high availability.

Question 9

What mounting options are available for this switch?

Accepted Answer

The switch supports DIN-rail and wall mounting kits for versatile installation in control cabinets or field sites.

Question 10

What VLAN and QoS features are available with an unmanaged switch?

Accepted Answer

As an unmanaged switch, it does not offer VLAN or QoS configuration but provides wire-speed switching for real-time traffic.

Question 11

What certifications ensure industrial reliability?

Accepted Answer

It is certified to EN 50155, EN 61000-6-2/4 for EMC immunity and emission, and UL/cUL Class I Division 2 safety standards.

Question 12

How does the IE-2000U-16TC-G-X handle power-over-Ethernet (PoE)?

Accepted Answer

This model does not support PoE; it is optimized for standard Ethernet connectivity without inline power.

Question 13

Can the IE-2000U-16TC-G-X be used outdoors?

Accepted Answer

With its rugged housing and extended temperature range, it can be deployed in protected outdoor enclosures but not fully exposed to direct weather.

Question 14

What is the MTBF of the IE-2000U-16TC-G-X?

Accepted Answer

The mean time between failures (MTBF) exceeds 250,000 hours, ensuring robust uptime in industrial settings.

Question 15

How do I troubleshoot port connectivity on the IE-2000U-16TC-G-X?

Accepted Answer

Check link/activity LEDs on each port for status, verify cable integrity, and ensure correct SFP module seating.

Question 16

What warranty and support options are available?

Accepted Answer

Cisco offers a limited lifetime warranty on the hardware and optional SMARTnet service for software updates and 24/7 technical support.

	IE-2000U-16TC-G-X	IE-2000-16TC-B	IE-2000-16T67-B	IE-2000-16TC-G-N	IE-2000-16TC-L
Depth	8 inches	11 inches	9 inches	12 inches	9 inches
Ethernet Technology	10/100	10/100/1000	10/100/1000	10/100/1000	10/100
Flash Memory	32 MB	32 MB	64 MB	64 MB	32 MB
Form Factor	Rack-mount	Rack-mount	Rack-mount	Rack-mount	Rack-mount
Height	1.75 inches	1.75 inches	1.75 inches	1.75 inches	1.75 inches
IOS	LAN Base	LAN Base	N/A	N/A	LAN Lite
Interface Ports	10/100	10/100/1000	10/100/1000	10/100/1000	10/100
Layer Supported	Layer 2	Layer 2	Layer 2	Layer 2	Layer 2
Manageable	Managed	Managed	Managed	Managed	Managed
Manufacturer Part Number	IE-2000U-16TC-G-X	IE-2000-16TC-B	IE-2000-16T67-B	IE-2000-16TC-G-N	IE-2000-16TC-L
Media Type Supported	Twisted Pair	Twisted Pair	Combo	Twisted Pair	Twisted Pair
Memory	128 MB	128 MB	256 MB	256 MB	256 MB
Number of Downlink Ports	16 Ports	8 Ports	16 Ports	16 Ports	16 Ports
Number of Ethernet Ports	12–24 Ports	12–24 Ports	12–24 Ports	12–24 Ports	12–24 Ports
POE Support	Non POE	Non POE	Non POE	Non POE	Non POE
Port/Expansion Slot Details	16 10/100 copper ports with 4 dedicated SFP uplink ports	16 Copper Ports, 4 SFP Ports	Stackable up to 8 units	16 x 10/100/1000 Ethernet ports and 4 x SFP uplink ports	16x 10/100 copper ports, 4x SFP uplink ports
Power Consumption	45 W	N/A	48 W	N/A	30W
Power Source	AC Power Supply	AC Power Supply	AC Power Supply	AC Power Supply	AC Power Supply
Product Name	IE-2000U-16TC-G-X Industrial Ethernet Switch	IE-2000-16TC-B Industrial Managed Switch	IE-2000-16T67-B Industrial Managed Switch	IE-2000-16TC-G-N Industrial Ethernet Switch	IE-2000-16TC-L Industrial Ethernet Switch
Product Type	Switch	Switch	Switch	Switch	Switch
Rack Units	1 RU	1 RU	1 RU	1 RU	1 RU
Redundant Power Supply Supported	No	No	Yes	No	No
SFP Ports	4 SFP Ports	4 SFP Ports	4 SFP Ports	4 SFP Ports	4 SFP Ports
Switching Capacity	3.2 Gbps	32 Gbps	32 Gbps	32 Gbps	3.2 Gbps
Switching Capacity with Stacking	6.4 Gbps	64 Gbps	64 Gbps	N/A	6.4 Gbps
Uplink Configuration	1G	1G	1G	1G	1G
Weight	8 lbs	7 lbs	12 lbs	8 lbs	7 lbs
Width	19 inches	17.5 inches	19 inches	17.5 inches	19 inches
